| Material: | 316L/SA516 Gr.70 | Structure: | Generating Reactor |
|---|---|---|---|
| Length: | 11000mm | Diameter: | 2500mm |
| Application: | ABS Project | Weight: | 10Tons |
| Other Available Materials: | Titanium & Titanium Alloy, Copper-Nickel Alloy, Zirconium, Tantalum |
ABS Project Chemical Process Equipment 316L / SA516 Gr.70 Reactor
1. Product Quick Description
Item Name: Chamber Reactor
Application: ABS Project
Material: 316L/SA516 Gr.70
Dimension:
Shell: Dia. 2500* Length 11000mm
Jacket: Dia. 2550* Length 8000mm
Weight: 10 tons
This equipment is used in the production process of hydrolysis, neutralization, crystallization,
distillation, evaporation and other processes in medicine, chemical, food and light industries.
It is acid resistance, high temperature resistance, wear resistance, and corrosion resistance.
It can also be produced as per users’ requirements.
2. Packing&Shipping
a. 100L~500L Reactor: Quality inspection - Wooden package - Truck loading - Container - Deliver by sea.
b. 1000L~10000L Reactor: Quality inspection - Plastic bag/ Film materials package - Truck loading - Container - Deliver by sea.
c. 10000L~40000L Reactor: Quality inspection - Film materials package/ Nude package - Truck loading - Container - Deliver by sea.
3. Certificate
Suntech has been certificated by ASME U,PED andNB which are accepted by many famous domestic and oversea companies. and also established the quality control systerm based on ISO-9001 which have been implemented to the process of R&D, fabrication, logistic , Markting and services.
4. Competitive Advantage
a.Abundant experience: more than one decade of abundant experience in non-ferrous metal
cladding and production;
b. Technical consulting service: technical consulting on material, welding, NDE, etc;
c. Independent inspection service; in-process inspection, final inspection;
d. Transportation advantage: 296kms away from Shanghai seaport
